Product Description
NHD possesses decades of experience in wire mesh production with a fully-integrated manufacturing system. As a designated supplier for the Ministry of Chemical Industry, China National Nonferrous Metals Corporation, and the petrochemical sector, NHD pioneered the development of three generations of wire mesh demisters. The Drawer-Type Wire Mesh Demister industry standard (issued by the Ministry of Chemical Industry) was adapted from NHD’s corporate standard.
Fine mist droplets move randomly due to Brownian motion, collide with the wire mesh or fibers, coalesce into larger droplets, and drain by gravity for efficient gas-liquid separation.
Model Evolution
1st Standard Type
Compact size, light weight, low resistance.
2nd Drawer Type
- No need to enter the tower for cleaning, repair, or replacement;
- Easy maintenance, extended service life, stable performance;
- Short downtime, low cost, simple structure;
- Blind plate option for low-load operation, enhancing adaptability.
3rd V Type
Retains all advantages of 1st & 2nd generations, with additional features:
- avoids re-entrainment for higher efficiency;
- increases effective demisting area by 15%;
- achieves dual-layer performance with single-layer installation.
